XPLORA R/T
Navigating its chiseled path, the powerhouse Federal Xplora R/T produces a herculean off-road experience with a delicate balance of roadside manners, offering rugged consumers the optimum balancing of vigorous durability off-road, diminished noise on-road, and incredible styling no matter where you adventure!
FEATURES
- Technologically advanced computer modeling for optimized tread pitch variation, perfectly placed tread sipes, and tread block alignment greatly reduce noise, providing a more civilized, comfortable, smooth, quiet ride.
- Stone ejectors prevent stone retention causing premature wear and failure, ensuring long life of tire by preventing premature wear.
- Enhanced fatigue resistant tread compound protects tire from chips/cuts/rocks/other debris, ensuring long life of tire by preventing early failure due to off-road use.
- Open shoulder grooves keep tire self-cleaning, evacuating water/mud/dirt/off-road debris, and providing confident traction in any condition.
- Linear center tread blocks enhance on-road straight line stability for excellent and more predictable handling with easy ride comfort.
Warning
SERIOUS INJURY OR DEATH MAY RESULT FROM：(A) Tire Failure due to underinflation and/or overloading. Consult the owner’s manual or vehicle tire placard. (B) Explosion of tire/rim assembly due to improper mounting. Only trained persons should mount tires.
TIRE MOUNTING SAFETY PRECAUTIONS：1. Follow RMA installation safety procedures for mounting and inflating tires. 2. Always match the rim diameter with tire diameter. 3. Never mount tire on a cracked, bent, or corroded rim. 4. Never put a flammable substance into a tire/rim assembly. 5. Always clean and lubricate rim and tire beads. 6. Never inflate a tire/rim assembly that is not restrained. 7. Always use a clip-on chuck and extension gauge on air hose when inflating and/or seating beads. 8. Never stand next to, lean or reach over the tire/rim assembly when inflating. 9. Never inflate over 40psi (275kPA) to seat beads. 10. Tire pressure should be adjusted to the recommended operating pressure after beads are seated.
Global Dimension Data
| SER | Size | LI/SS | PR | Overall Diameter |
Section Width |
Standard Rim in |
Approved Rim Width in |
Tread Width |
Tread Depth |
Max. Air Pressure psi |
Max. Load |
UTQG | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in32" | KG | lbs | ||||||||
| 15 | 31X10.50R15LT | 109Q | 6 | 778 | 30.6 | 281 | 11.1 | 8.5 | 7.0 ~ 9.0 | 220 | 8.7 | 14.0 | 18 | 50 | 1030 | 2270 | |
| 16 | LT235/85R16 | 120/116Q | 10 | 805 | 31.7 | 236 | 9.3 | 6.5 | 6.0 ~ 7.5 | 193 | 7.6 | 13.0 | 16 | 80 | 1380/1260 | 3042/2778 | |
| LT245/75R16 | 120/116Q | 10 | 773 | 30.4 | 252 | 9.9 | 7.0 | 6.5 ~ 8.0 | 203 | 8.0 | 13.0 | 16 | 80 | 1380/1260 | 3042/2778 | ||
| LT265/75R16 | 123/120Q | 10 | 801 | 31.5 | 272 | 10.7 | 7.5 | 7.0 ~ 9.0 | 219 | 8.6 | 13.0 | 16 | 80 | 1550/1400 | 3415/3085 | ||
| LT285/75R16 | 126/123Q | 10 | 833 | 32.8 | 288 | 11.3 | 8.0 | 7.5 ~ 9.5 | 235 | 9.3 | 13.0 | 16 | 80 | 1700/1550 | 3750/3415 | ||
| LT315/75R16 | 127/124R | 10 | 876 | 34.5 | 322 | 12.7 | 8.5 | 8.0 ~ 10.5 | 257 | 10.1 | 13.0 | 16 | 65 | 1750/1600 | 3860/3525 | ||
| 17 | 35X12.50R17LT | 137Q | 10 | 882 | 34.7 | 328 | 12.9 | 10.0 | 8.5 ~ 11.0 | 254 | 10.0 | 14.4 | 18 | 65 | 1650 | 3638 | |
| 37X12.50R17LT | 137Q | 10 | 934 | 36.8 | 327 | 12.9 | 10.0 | 8.0 ~ 10.5 | 254 | 10.0 | 15.0 | 19 | 65 | 1850 | 4078 | ||
| LT265/65R17 | 120/117R | 10 | 779 | 30.7 | 265 | 10.4 | 8.0 | 8.0 ~ 9.5 | 223 | 8.8 | 13.0 | 16 | 80 | 1400/1285 | 3085/2835 | ||
| LT265/70R17 | 121/118Q | 10 | 804 | 31.7 | 270 | 10.6 | 8.0 | 7.0 ~ 9.0 | 223 | 8.8 | 13.0 | 16 | 80 | 1450/1320 | 3195/2910 | ||
| LT285/70R17 | 121/118Q | 10 | 832 | 32.8 | 282 | 11.1 | 8.5 | 7.5 ~ 9.5 | 229 | 9.0 | 13.0 | 16 | 80 | 1450/1320 | 3195/2910 | ||
| LT315/70R17 | 121/118Q | 10 | 871 | 34.3 | 329 | 12.9 | 9.5 | 8.0 ~ 10.5 | 265 | 10.4 | 13.0 | 16 | 65 | 1450/1320 | 3195/2910 | ||
| 18 | 35X12.50R18LT | 123Q | 10 | 883 | 34.8 | 322 | 12.7 | 10.0 | 8.5 ~ 11.0 | 254 | 10.0 | 15.0 | 19 | 65 | 1550 | 3415 | |
| LT265/65R18 | 122/119R | 10 | 803 | 31.6 | 263 | 10.4 | 8.0 | 8.0 ~ 9.5 | 223 | 8.8 | 13.0 | 16 | 80 | 1500/1360 | 3305/3000 | ||
| LT275/65R18 | 123/120Q | 10 | 818 | 32.2 | 272 | 10.7 | 8.0 | 8.0 ~ 9.5 | 229 | 9.0 | 13.0 | 16 | 80 | 1550/1400 | 3415/3085 | ||
| LT275/70R18 | 125/122Q | 10 | 844 | 33.2 | 277 | 10.9 | 8.0 | 7.0 ~ 9.0 | 229 | 9.0 | 13.0 | 16 | 80 | 1500/1650 | 3305/3640 | ||
| LT285/60R18 | 122/119S | 10 | 799 | 31.5 | 281 | 11.1 | 8.5 | 8.5 ~ 10.0 | 239 | 9.4 | 13.0 | 16 | 80 | 1500/1360 | 3305/3000 | ||
| LT305/60R18 | 121/118Q | 10 | 822 | 32.4 | 300 | 11.8 | 9.0 | 9.0 ~ 11.0 | 255 | 10.0 | 13.0 | 16 | 65 | 1320/1450 | 2910/3195 | ||
| LT305/70R18 | 126/123Q | 10 | 883 | 34.8 | 310 | 12.2 | 9.0 | 8.0 ~ 10.0 | 255 | 10.0 | 13.0 | 16 | 65 | 1700/1550 | 3750/3415 | ||
| 20 | 33X12.50R20LT | 114Q | 10 | 832 | 32.8 | 305 | 12.0 | 10.0 | 8.5 ~ 11.0 | 254 | 10.0 | 14.4 | 18 | 65 | 1180 | 2600 | |
| 33X12.50R22LT | 114Q | 12 | 834 | 32.8 | 292 | 11.5 | 10.0 | 8.5 ~ 11.0 | 261 | 10.3 | 14.4 | 18 | 80 | 1180 | 2600 | ||
| 35X12.50R20LT | 121Q | 10 | 882 | 34.7 | 316 | 12.4 | 10.0 | 8.5 ~ 11.0 | 254 | 10.0 | 14.4 | 18 | 65 | 1450 | 3195 | ||
| 35X12.50R22LT | 121Q | 12 | 884 | 34.8 | 296 | 11.6 | 10.0 | 8.5 ~ 11.0 | 261 | 10.3 | 14.4 | 18 | 80 | 1450 | 3195 | ||
| LT265/50R20 | 121/118S | 10 | 774 | 30.5 | 251 | 9.9 | 8.5 | 8.0 ~ 9.5 | 227 | 8.9 | 13.0 | 16 | 80 | 1450/1320 | 3195/2910 | ||
| LT275/65R20 | 126/123Q | 10 | 866 | 34.1 | 279 | 11.0 | 8.0 | 8.0 ~ 9.5 | 229 | 9.0 | 13.0 | 16 | 80 | 1700/1550 | 3750/3415 | ||
| LT285/60R20 | 125/122S | 10 | 851 | 33.5 | 279 | 11.0 | 8.5 | 8.5 ~ 10.0 | 239 | 9.4 | 13.0 | 16 | 80 | 1650/1500 | 3640/3305 | ||
Europe Dimension Data
| SER | Size | LI/SS | PR | Overall Diameter |
Section Width |
Standard Rim in |
Approved Rim Width in |
Tread Width |
Tread Depth |
Max. Air Pressure psi |
Max. Load |
UTQG | Tyres | RR | Wet Grip |
dBS | E_sound | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in32" | KG | lbs | |||||||||||||
| For details please contact our sales representatives. | ||||||||||||||||||||||
