SS657
The Super Steel 657 delivers passenger car drivers smooth driving, tranquility, and long tread life.
FEATURES
- Optimized pattern design reduces noise and vibration for quiet and comfortable rides.
- Wide circumferential grooves enable rapid water channeling and reduced aquaplaning on wet roads.
- Excellent all-around, wet and dry performance, plus long tread life for highway and everyday driving.
Warning
SERIOUS INJURY OR DEATH MAY RESULT FROM：(A) Tire Failure due to underinflation and/or overloading. Consult the owner’s manual or vehicle tire placard. (B) Explosion of tire/rim assembly due to improper mounting. Only trained persons should mount tires.
TIRE MOUNTING SAFETY PRECAUTIONS：1. Follow RMA installation safety procedures for mounting and inflating tires. 2. Always match the rim diameter with tire diameter. 3. Never mount tire on a cracked, bent, or corroded rim. 4. Never put a flammable substance into a tire/rim assembly. 5. Always clean and lubricate rim and tire beads. 6. Never inflate a tire/rim assembly that is not restrained. 7. Always use a clip-on chuck and extension gauge on air hose when inflating and/or seating beads. 8. Never stand next to, lean or reach over the tire/rim assembly when inflating. 9. Never inflate over 40psi (275kPA) to seat beads. 10. Tire pressure should be adjusted to the recommended operating pressure after beads are seated.
Global Dimension Data
| SER | Size | LI/SS | PR | Overall Diameter |
Section Width |
Standard Rim in |
Approved Rim Width in |
Tread Width |
Tread Depth |
Max. Air Pressure psi |
Max. Load |
UTQG | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in32" | KG | lbs | ||||||||
| 12 | 155/80R12 | 77T | 554 | 21.8 | 160 | 6.3 | 4.5 | 4.0 ~ 5.5 | 107 | 4.2 | 7.2 | 9 | 44 | 412 | 908 | 420A A | |
| 13 | 175/70R13 | 82T | 581 | 22.9 | 173 | 6.8 | 5.0 | 4.5 ~ 5.5 | 127 | 5.0 | 7.7 | 10 | 44 | 475 | 1047 | 420A A | |
| 14 | 165/65R14 | 79T | 569 | 22.4 | 160 | 6.3 | 5.0 | 4.5 ~ 6.0 | 124 | 4.9 | 7.6 | 10 | 44 | 437 | 963 | 420A A | |
| 175/65R14 | 82T | 584 | 23.0 | 176 | 6.9 | 5.0 | 5.0 ~ 6.0 | 136 | 5.4 | 7.7 | 10 | 44 | 475 | 1047 | 420A A | ||
| 175/70R14 | 84T | 600 | 23.6 | 179 | 7.0 | 5.0 | 4.5 ~ 6.0 | 124 | 4.9 | 7.8 | 10 | 44 | 500 | 1102 | 420A A | ||
| 185/60R14 | 82H | 581 | 22.9 | 184 | 7.2 | 5.5 | 5.0 ~ 6.0 | 148 | 5.8 | 8.0 | 10 | 44 | 475 | 1047 | 420A A | ||
| 185/65R14 | 86H | 595 | 23.4 | 185 | 7.3 | 5.5 | 5.0 ~ 6.5 | 146 | 5.7 | 7.6 | 10 | 44 | 530 | 1168 | 420A A | ||
| 185/65R14 | 86T | 595 | 23.4 | 185 | 7.3 | 5.5 | 5.0 ~ 6.5 | 146 | 5.7 | 8.2 | 10 | 44 | 530 | 1168 | 420A A | ||
| 185/70R14 | 88T | 620 | 24.4 | 191 | 7.5 | 5.5 | 4.5 ~ 6.0 | 132 | 5.2 | 7.9 | 10 | 44 | 560 | 1235 | 420A A | ||
| 195/60R14 | 86H | 590 | 23.2 | 190 | 7.5 | 6.0 | 5.5 ~ 6.5 | 156 | 6.1 | 7.9 | 10 | 44 | 530 | 1168 | 420A A | ||
| 195/65R14 | 89H | 611 | 24.0 | 196 | 7.7 | 6.0 | 5.5 ~ 6.5 | 152 | 6.0 | 8.2 | 10 | 44 | 580 | 1279 | 420A A | ||
| 195/70R14 | 91T | 632 | 24.9 | 208 | 8.2 | 6.0 | 5.0 ~ 6.5 | 138 | 5.4 | 8.1 | 10 | 44 | 615 | 1355 | 420A A | ||
| 205/60R14 | 89H | 605 | 23.8 | 202 | 8.0 | 6.0 | 5.5 ~ 6.5 | 164 | 6.5 | 8.3 | 10 | 44 | 580 | 1279 | 420A A | ||
| 215/65R14 | 94H | 638 | 25.1 | 218 | 8.6 | 6.5 | 6.0 ~ 7.0 | 167 | 6.6 | 8.5 | 11 | 44 | 670 | 1477 | 420A A | ||
| 15 | 165/80R15 | 87T | 644 | 25.4 | 168 | 6.6 | 4.5 | 4.0 ~ 5.5 | 114 | 4.5 | 7.8 | 10 | 44 | 545 | 1202 | 420A A | |
| 185/60R15 | 84H | 607 | 23.9 | 184 | 7.2 | 5.5 | 5.0 ~ 6.0 | 148 | 5.8 | 8.0 | 10 | 44 | 500 | 1102 | 420A A | ||
| 185/65R15 | 88H | 623 | 24.5 | 185 | 7.3 | 5.5 | 5.0 ~ 6.0 | 144 | 5.7 | 8.1 | 10 | 44 | 560 | 1235 | 420A A | ||
| 195/60R15 | 88H | 615 | 24.2 | 202 | 8.0 | 6.0 | 5.5 ~ 6.5 | 156 | 6.1 | 7.9 | 10 | 44 | 560 | 1235 | 420A A | ||
| 195/65R15 | 91H | 636 | 25.0 | 201 | 7.9 | 6.0 | 5.5 ~ 7.0 | 145 | 5.7 | 8.2 | 10 | 44 | 615 | 1355 | 420A A | ||
| 195/65R15 | 91T | 636 | 25.0 | 201 | 7.9 | 6.0 | 5.5 ~ 7.0 | 145 | 5.7 | 8.2 | 10 | 44 | 615 | 1355 | 420A A | ||
| 205/60R15 | 91H | 628 | 24.7 | 206 | 8.1 | 6.0 | 5.5 ~ 6.5 | 168 | 6.6 | 8.4 | 11 | 44 | 615 | 1356 | 420A A | ||
| 205/65R15 | 95H | 647 | 25.5 | 205 | 8.1 | 6.0 | 5.5 ~ 6.5 | 162 | 6.4 | 8.0 | 10 | 44 | 690 | 1521 | 420A A | ||
| 215/60R15 | 94H | 642 | 25.3 | 218 | 8.6 | 6.5 | 6.0 ~ 7.0 | 172 | 6.8 | 8.5 | 11 | 44 | 670 | 1477 | 420A A | ||
| 215/65R15 | 96H | 663 | 26.1 | 216 | 8.5 | 6.5 | 6.0 ~ 7.0 | 167 | 6.6 | 8.5 | 11 | 44 | 710 | 1565 | 420A A | ||
| 225/60R15 | 96H | 651 | 25.6 | 223 | 8.8 | 6.5 | 6.0 ~ 7.0 | 180 | 7.1 | 8.6 | 11 | 44 | 710 | 1565 | 420A A | ||
| P205/65R15 | 95T XL | 647 | 25.5 | 208 | 8.2 | 6.0 | 5.5 ~ 6.5 | 160 | 6.3 | 8.1 | 10 | 50 | 690 | 1521 | 420A A | ||
| 16 | 205/60R16 | 92H | 653 | 25.7 | 203 | 8.0 | 6.0 | 5.5 ~ 6.5 | 164 | 6.5 | 8.4 | 11 | 44 | 630 | 1389 | 420A A | |
| 215/60R16 | 95H | 664 | 26.2 | 221 | 8.7 | 6.5 | 6.0 ~ 7.0 | 172 | 6.8 | 8.6 | 11 | 44 | 690 | 1521 | 420A A | ||
| 215/65R16 | 98H | 686 | 27.0 | 219 | 8.6 | 6.5 | 6.0 ~ 7.5 | 160 | 6.3 | 7.9 | 10 | 44 | 750 | 1653 | 420A A | ||
| 225/60R16 | 98H | 678 | 26.7 | 228 | 9.0 | 6.5 | 6.0 ~ 8.0 | 184 | 7.2 | 8.7 | 11 | 44 | 750 | 1653 | 420A A | ||
| 235/60R16 | 100H | 691 | 27.2 | 236 | 9.3 | 7.0 | 6.5 ~ 7.5 | 187 | 7.4 | 8.8 | 11 | 44 | 800 | 1764 | 420A A | ||
Europe Dimension Data
| SER | Size | LI/SS | PR | Overall Diameter |
Section Width |
Standard Rim in |
Approved Rim Width in |
Tread Width |
Tread Depth |
Max. Air Pressure psi |
Max. Load |
UTQG | Tyres | RR | Wet Grip |
dBS | E_sound | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in32" | KG | lbs | |||||||||||||
| For details please contact our sales representatives. | ||||||||||||||||||||||
