SUV & 4X4

COURAGIA M/T

The mighty Couragia M/T is legendary for its toughness, maximum off-road traction, and deep-biting tread blocks.

4x4
Light truck
Off Road
Mud Terrain
M+S
All Season

FEATURES

  1. Reinforced compounds contribute to exceptional durability against cuts, chips, and abrasions.
  2. Aggressive tread design and strengthened shoulder deliver excellent traction and protection from off-road impact.
  3. Optimized block design increases off-road traction and control.
  4. Uniquely designed incremental block edge quickly sheds dirt, sand, and gravel for ultimate off-road traction.

Warning

SERIOUS INJURY OR DEATH MAY RESULT FROM:(A) Tire Failure due to underinflation and/or overloading. Consult the owner’s manual or vehicle tire placard. (B) Explosion of tire/rim assembly due to improper mounting. Only trained persons should mount tires.

TIRE MOUNTING SAFETY PRECAUTIONS:1. Follow RMA installation safety procedures for mounting and inflating tires. 2. Always match the rim diameter with tire diameter. 3. Never mount tire on a cracked, bent, or corroded rim. 4. Never put a flammable substance into a tire/rim assembly. 5. Always clean and lubricate rim and tire beads. 6. Never inflate a tire/rim assembly that is not restrained. 7. Always use a clip-on chuck and extension gauge on air hose when inflating and/or seating beads. 8. Never stand next to, lean or reach over the tire/rim assembly when inflating. 9. Never inflate over 40psi (275kPA) to seat beads. 10. Tire pressure should be adjusted to the recommended operating pressure after beads are seated.

Global Dimension Data

Horizontal Scrolling
SER Size LI/SS PR Overall
Diameter
Section
Width
Standard
Rim
in
Approved
Rim Width
in
Tread
Width
Tread
Depth
Max. Air
Pressure
psi
Max.
Load
UTQG
mm in mm in mm in mm in32" KG lbs
15 30X9.50R15LT 104Q 6 757 29.8 252 9.9 7.5 6.5 ~ 8.5 192 7.6 15.0 19 35 900 1985
31X10.50R15LT 109Q 6 785 30.9 268 10.6 8.5 7.0 ~ 9.0 200 7.9 15.0 19 50 1030 2270
33X12.50R15LT 108Q 6 833 32.8 325 12.8 10.0 8.5 ~ 11.0 248 9.8 15.0 19 35 1000 2205
35X12.50R15LT 113Q 6 883 34.8 343 13.5 10.0 9.5 ~ 10.5 252 9.9 16.7 21 35 1150 2535
LT235/75R15 104/101Q 6 734 28.9 228 9.0 6.5 6.0 ~ 7.0 168 6.6 15.0 19 50 900/825 1985/1820
16 LT205/80R16 110/108P 8 734 28.9 210 8.3 5.5 5.0 ~ 7.0 160 6.3 15.0 19 65 1060/1000 2337/2205
LT235/85R16 120/116Q 10 806 31.7 231 9.1 6.5 6.0 ~ 7.5 170 6.7 15.0 19 80 1400/1260 3086/2778
17 37X12.50R17LT 131Q 12 933 36.7 327 12.9 10.0 8.0 ~ 11.0 251 9.9 15.0 19 65 1850 4080
18 35X12.50R18LT 123Q 10 886 34.9 309 12.2 10.0 9.5 ~ 10.5 248 9.8 16.7 21 65 1550 3415

Europe Dimension Data

Horizontal Scrolling
SER Size LI/SS PR Overall
Diameter
Section
Width
Standard
Rim
in
Approved
Rim Width
in
Tread
Width
Tread
Depth
Max. Air
Pressure
psi
Max.
Load
UTQG Tyres RR Wet
Grip
dBS E_sound
mm in mm in mm in mm in32" KG lbs
For details please contact our sales representatives.
